Forklift Starters and Alternators

Forklift Starters and Alternators - Today's starter motor is usually a permanent-magnet composition or a series-parallel wound direct current electrical motor together with a starter solenoid installed on it. As soon as current from the starting battery is applied to the solenoid, mainly through a key-operated switch, the solenoid engages a lever that pushes out the drive pinion that is positioned on the driveshaft and meshes the pinion utilizing the starter ring gear which is found on the engine flywheel.

When the starter motor begins to turn, the solenoid closes the high-current contacts. As soon as the engine has started, the solenoid consists of a key operated switch which opens the spring assembly to be able to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This permits the pinion to transmit drive in just a single direction. Drive is transmitted in this method through the pinion to the flywheel ring gear. The pinion remains engaged, like for example in view of the fact that the operator fails to release the key when the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin independently of its driveshaft.

The actions discussed above will prevent the engine from driving the starter. This important step prevents the starter from spinning very fast that it could fly apart. Unless modifications were done, the sprag clutch arrangement will stop the use of the starter as a generator if it was utilized in the hybrid scheme mentioned prior. Typically a regular starter motor is meant for intermittent use which would stop it being utilized as a generator.

The electrical components are made in order to operate for more or less 30 seconds to avoid overheating. Overheating is caused by a slow dissipation of heat is because of ohmic losses. The electrical components are intended to save weight and cost. This is really the reason the majority of owner's manuals utilized for automobiles recommend the driver to stop for at least ten seconds right after each ten or fifteen seconds of cranking the engine, when trying to start an engine that does not turn over right away.

In the early 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Prior to that time, a Bendix drive was utilized. The Bendix system works by placing the starter drive pinion on a helically cut driveshaft. When the starter motor starts turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, hence engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear allows the pinion to exceed the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.

The development of Bendix drive was developed during the 1930's with the overrunning-clutch design known as the Bendix Folo-Thru drive, made and launched in the 1960s. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights in the body of the drive unit. This was much better in view of the fact that the average Bendix drive used so as to disengage from the ring once the engine fired, even if it did not stay functioning.

When the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, like for instance it is backdriven by the running engine, and next the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement could be avoided previous to a successful engine start.
