Forklift Starter

Forklift Starters - Today's starter motor is normally a permanent-magnet composition or a series-parallel wound direct current electrical motor with a starter solenoid mounted on it. When current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever that pushes out the drive pinion which is positioned on the driveshaft and meshes the pinion utilizing the starter ring gear which is seen on the flywheel of the engine.

The solenoid closes the high-current contacts for the starter motor, which starts to turn. After the engine starts, the key operated switch is opened and a spring within the solenoid assembly pulls the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This permits the pinion to transmit drive in just a single direction. Drive is transmitted in this way via the pinion to the flywheel ring gear. The pinion remains engaged, for example in view of the fact that the driver did not release the key as soon as the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin independently of its driveshaft.

This aforementioned action stops the engine from driving the starter. This is actually an essential step in view of the fact that this particular type of back drive would enable the starter to spin so fast that it would fly apart. Unless modifications were done, the sprag clutch arrangement will stop utilizing the starter as a generator if it was made use of in the hybrid scheme discussed prior. Usually a standard starter motor is intended for intermittent use that will stop it being used as a generator.

Hence, the electrical components are designed to work for just about under 30 seconds to prevent overheating. The overheating results from too slow dissipation of heat because of ohmic losses. The electrical parts are meant to save weight and cost. This is truly the reason the majority of owner's instruction manuals used for vehicles recommend the driver to stop for at least ten seconds right after each ten or fifteen seconds of cranking the engine, if trying to start an engine which does not turn over instantly.

The overrunning-clutch pinion was introduced onto the marked in the early part of the 1960's. Before the 1960's, a Bendix drive was utilized. This drive system works on a helically cut driveshaft which consists of a starter drive pinion placed on it. As soon as the starter motor begins turning, the inertia of the drive pinion assembly enables it to ride forward on the helix, thus engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear allows the pinion to go beyond the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.

During the 1930s, an intermediate development between the Bendix drive was developed. The overrunning-clutch design that was developed and launched in the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive has a latching mechanism along with a set of flyweights within the body of the drive unit. This was better as the typical Bendix drive utilized so as to disengage from the ring once the engine fired, although it did not stay running.

The drive unit if force forward by inertia on the helical shaft as soon as the starter motor is engaged and begins turning. After that the starter motor becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, for example it is backdriven by the running engine, and then the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement can be avoided prior to a successful engine start.
